Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Specifications
  • CPU

Qualcomm, @650 MHz

  • Memory / Storage

DDR2 128 MB + NOR 16 MB

  • Protocol

802.11b/g/n

  • Wi-Fi Speed

2.4 GHz: 300 Mbps

  • Ethernet Speed

10/100Mbps

  • Power Input

DC5521, 12V/1A (5.5*2.1 mm), 9V ~ 36V

  • Power Consumption

<4W

  • Dimension / Weight

104*113*28 mm / 235g

Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version

$105.99
$105.99 - $105.99
$105.99
$105.99

  • Hassle-Free 2 Year Warranty

  • Free shipping to select countries

  • 30 Day Moneyback

Region:
Before You Buy:
  • Cellular router category is restricted in Russia, Belarus, Cuba, Iran, North Korea, Syria, and the Crimean Peninsula due to modem limitations.
  • VAT is included in prices displayed currently for orders to Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, and Sweden.
  • Sales Tax will be charged at checkout for orders shipped to the United States and Canada. Please refer to the price displayed on the checkout page.
Bulk Orders:

For larger orders of more than 30 units, kindly contact our customer service team at cs@gl-inet.com.

Specifications
  • CPU

Qualcomm, @650 MHz

  • Memory / Storage

DDR2 128 MB + NOR 16 MB

  • Protocol

802.11b/g/n

  • Wi-Fi Speed

2.4 GHz: 300 Mbps

  • Ethernet Speed

10/100Mbps

  • Power Input

DC5521, 12V/1A (5.5*2.1 mm), 9V ~ 36V

  • Power Consumption

<4W

  • Dimension / Weight

104*113*28 mm / 235g

Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
Collie (GL-X300B) Industrial 4G Gateway | RS485 | EG25-G Global Version
$105.99
$105.99 - $105.99
$105.99
$105.99
Collie / GL-X300B
GL-X300B-BLE / GL-X300B-GPS / GL-X300B-RS485

MEET COLLIE

4G LTE Industrial Wireless IoT Gateway

4G LTE Industrial Wireless Gateway

Collie (GL-X300B) is an industrial cellular gateway designed to operate under high temperatures and scenarios with potential physical hazards. There are two versions of Collie, designed to operate in indoor stationary facilities, or in transportation vehicles. Collie is perfect for machine-to-machine communications between electrical devices in high electrical noise environments.

Built-in 4G Module
Built for Stationary IoT or Vehicle Location Tracking
Built-in Hardware Watchdog
Learn More View Online Guide

Model Comparison


GL-X300B-RS485
GL-X300B-BLE*
GL-X300B-GPS*
CPU QCA9531, @650MHz SoC QCA9531, @650MHz SoC QCA9531, @650MHz SoC
Memory / Storage DDR2 128MB / NOR Flash 16MB DDR2 128MB / NOR Flash 16MB DDR2 128MB / NOR Flash 16MB
2.4G Wi-Fi 300Mbps 150Mbps 300Mbps
Wi-Fi Antennas (2.4GHz) 2 1 2
4G LTE Antennas 1 1 2
BLE Antennas 1
GPS Antennas 1
4G Module CAT 4 CAT 4 CAT 4
Ethernet Ports 2 x 10/100Mbps 2 x 10/100Mbps 2 x 10/100Mbps
SIM Card Slot
Hardware Watchdog
*The BLE and GPS versions are available with a minimum order quantity

Powerful Antennas For Maintaining Stable Networks

GL-X300B-GPS is equipped with five external antennas, including two 2.4GHz Wi-Fi, two 4G LTE, and one GPS Antenna. The extendable wired antennas are perfect for having multiple reception placements within a vehicle, minimizing reception black spots when traveling through high network density cities.

GL-X300B-BLE is equipped with three external omnidirectional antennas for 2.4GHz Wi-Fi, 4G LTE, and BLE communication, receiving signals from all directions, and providing high flexibility in installation placement within an industrial environment.

GL-X300B-RS485 includes an RS485 chip with RS485 interface. The module supports bi-directional data transmission of various devices in the field of industrial automation and IoT, thus realizing the functions of data acquisition, control and monitoring.

For Wall Mounted Applications

Collie's mounting platform has screw slots for wall mounting in an industrial environment, conveniently deploy the device in a safe position with minimal physical interference for reliable wireless connection.

For DIN Rail Mounted Applications

Collie's mounting platform is conveniently designed to fit in a DIN rail along with other electrical equipment, simplifying the deployment of an organized wiring design within an electrical enclosure or in other industrial environments.

30+ VPN SERVICE PROVIDERS FOR YOUR SELECTION

Securing Your Internet In The Background

Collie (GL-X300B) is pre-installed with OpenVPN and WireGuard® supporting 30+ VPN services. It automatically encrypts all network traffic within the connected network, including guest devices and client devices that are not capable of running VPN encryption. Collie (GL-X300B) can also act as a VPN server, redirecting traffic from client devices in remote locations to the VPN server via a VPN tunnel before accessing the public internet.

WireGuard® is a registered trademark of Jason A.Donenfeld.

WireGuard
Max. 38Mbps

OpenVPN
Max. 10Mbps
* Tests conducted on a local network. Real world speeds may differ depending on your network configuration.
* OpenVPN and WireGuard speeds will be slower when running the device as a server. Results above are in client mode.
30+ Commercial VPN services provider

Remote Access and Management

Collie comes with GL.iNet's GoodCloud remote device & networks management platform, providing users with data usage monitoring and technical support services with remote access to the device admin panel for maintenance and troubleshooting. It also enables batch device management, firmware updates, analytics and notifications for status updates, enabling users to manage devices efficiently.

Compatible with GL.iNet eSIM Solution

Compatible with GL.iNet eSIM Solution

Experience seamless connectivity with the Collie, fully compatible with GL.iNet’s advanced eSIM solution, which supports both physical eSIM cards and integrated eSIM chips*. eSIMs can be programmed remotely, offering unmatched convenience, flexibility, space-saving, and enhanced security. For consumers, this means effortlessly switching networks and avoiding roaming charges, while businesses benefit from centralized management, multi-device support, and secure data management.

*The feature currently requires pairing a physical eSIM card with our firmware. Integrated eSIM chip is available for bulk orders only.
Learn More

Enterprise Solutions

Robust VPN Gateway for Remote Access

Industrial Grade LTE Module
Learn more about GL-X300B use case Consult Experts

A Comprehensive Range of Connectivity Hardware and Software

Expand your service portfolio and widen your solution coverage by using Collie (GL-X300B) in your business operations. Our proven success in design and manufacturing multi-purpose routers & IoT gateways as well as delivering customized software solutions will be a seamless integration to your service portfolio.

Pre-Design - Application Scenario and Goals
Design Specifications
Solution Prototype and Testing
Mass Production or Scalable Integration
Learn More About Our White Label Service Contact Sales

Vehicles Location Tracking Using GL-X300B-GPS

GL-X300B-GPS includes a location tracking feature with an external GPS antenna. The module provides location data accessible on GoodCloud, and customisable to develop long-range asset tracking applications such as viewing public transport movement.

RV

Providing stable cellular networks to RV vehicles travelling in remote locations with minimal network infrastructure, and providing real-time location data.

Public Transport

Offering reliable cellular services and providing real-time vehicle location data at minimal interference on public transportation in high network density city environments.

Logistics Monitoring

Collecting and uploading data from vehicle charging stations to the cloud, and providing real-time status updates using third party applications.

Emergency Service Vehicles

Syncing data from on-board service equipment to cloud servers for hastened response and tracking vehicle location in real time.

Learn More About Our 4G Solutions Contact Sales

IoT Machine-to-Machine Communication Using GL-X300B-BLE

GL-X300B-BLE includes a BLE module with an external BLE Antenna. The module supports heavy-duty IoT machine-to-machine network communication for a wide range of IoT devices and applications, including equipment management, HVAC configuration, and large-scale logistical management scenarios.

Warehouse Logistics

Regulates indoor assets by tracking its storage location, indoor movement, and making real time adjustments to HVAC sensors and regulators.

Manufacturing

Establishing machine-to-machine communications and making real-time micro-adjustments to equipment according to sensor data.

Vehicle Charging Stations

Collecting and uploading data from vehicle charging stations to the cloud, and providing real-time status updates using third party applications.

Clinics and Hospitals

Tracking device data from medical sensors and equipment, remote monitoring patient vitals and receiving emergency notifications.

Learn More About Our Gateway to Cloud IoT Solutions Contact Sales
OpenWrt Ready
OpenWrt
Ready
VPN Client/Server
VPN Client /
Server
4G LTE Module
4G LTE
Module
Hardware Watchdog
Hardware
Watchdog
BLE
BLE1
GPS
GPS2
1Only applicable for GL-X300B-BLE| 2Only applicable for GL-X300B-GPS

Product Reviews from Our Customers

Specifications

Interface 1 x WAN Ethernet Port
1 x LAN Ethernet Port
1 X Standard SIM Card Slot
1 x Power Port
1 x Reset Button
CPU QCA9531, @650MHz SoC
Memory / Storage DDR2 128MB + NOR Flash 16MB
External Antennas GL-X300B-BLE: 1 x 2.4G Antenna, 1 x 4G LTE Antenna, 1 x BLE Antenna
GL-X300B-GPS: 2 x 2.4G Antennas, 2 x 4G LTE Antennas, 1 x GPS Antenna
GL-X300B-RS485: 2 x 2.4G Antennas, 1 x 4G LTE Antennas
Wi-Fi Protocol IEEE 802.11b/g/n
Wi-Fi Speed GL-X300B-BLE: 150Mbps (2.4GHz) / GL-X300B-GPS: 300Mbps (2.4GHz) / GL-X300B-RS485: 300Mbps (2.4GHz)
Ethernet Speed 10/100Mbps
LEDs Power, Wi-Fi, 4G and WAN
Power Supply DC5521, 12V/1A (5.5*2.1mm) [default adapter] / 9~36V
Power Consumption <4W
Operating Temperature -20 ~ 55°C (-4 ~ 131°F)
Storage Temperature -30 ~ 70°C (-22 ~ 158°F)
Dimension / Weight 104 x 113 x 28mm / 235g
Tools & Downloadables Datasheet | Firmware | App | Tutorials | Media Kit

Looking for Bulk Purchase?

Contact Our Sales Manager

Frequently Asked Questions

  • Visit the User Guide page and choose the product model and specification required for setup from the options on the left-hand side of the page.

  • Navigate to the OpenVPN Client Configuration section, where you can follow the provided guide to effortlessly unlock NordVPN and OpenVPN settings, ensuring seamless VPN functionality.

  • Visit the WireGuard VPN Client page and refer to the guide to effortlessly configure settings for AzireVPN, Mullvad, and other WireGuard client features.

  • Repeater Mode Basic Setup Guide

  • Proceed to the Tutorials section and refer to the guide to effortlessly complete the setup of your WireGuard Home Server.

  • Visit the FAQ page and search for the "Can't access the web Admin Panel" section to find the specific reasons and solutions for this issue.
